減速比:1/4, 1/5
最大額定力矩:5.0 kgf.cm
最大損壞扭力:15.5 kgf.cm
效率:80%
主要用途:電動門窗、安防設備、智能自動餐桌
減速電機主要技術參數 Reducer motor Technical Data
減速比 Max.Gearbr eaking torque | 最大額定力矩 Max.Running.to rque | 最大損壞扭力 Max.Gearbr eaking torque
| 效率 Gearing effic iency
| 級數 Number of stages
| 減速電機長度 Reducer motor length"L"mm
|
1/4, 1/5 | 5.0 kgf.cm
| 15.5 kgf.cm
| 80%
| 1 | 82.4 |
1/14, 1/19, 1/27
| 15.0 kgf.cm
| 50.0 kgf.cm
| 70%
| 2
| 89.5 |
1/51, 1/71, 1/100, 1/139
| 50.0 kgf.cm
| 150.0 kgf.cm
| 60%
| 3 | 97.0
|
1/189, 1/264, 1/369,1/516, 1/721
| 50.0 kgf.cm | 150.0 kgf.cm | 50%
| 4 | 103.9
|
1/699, 1/977, 1/1367,1/1911, 1/2672, 1/3736
| 50.0 kgf.cm | 150.0 kgf.cm
| 40%
| 5
| 111.0 |
馬達清單 Motor data
馬達型號 Motor type
| 額定電壓 額定電壓 (v) | 空載電流 No load current (mA)
| 空載轉速 No load speed (rpm) | 額定電流 Rated current (mA)
| 額定轉速 Rated speed (rpm)
| 額定扭力 Rated torque (gf.cm)
| 額定功率 Rated power (w) | 堵轉扭力 Stall torque (gf.cm) | 堵轉電流 Stall current (mA) | 重量 Weight (g)
|
DC-555126000
| 12
| ≤500 | 6000
| ≤2600
| 5000 | 320
| 16.3
| ≤2049 | ≤14300
| 224.0 |
DC-555246000
| 24 | ≤280
| 6000
| ≤1200
| 5000
| 285
| 14.4 | ≤1963 | ≤6850 | 224.0 |
